transfer and carry away the evaporated moisture. Most of the damp air flows back to the circulation fan for the next drying circulation while part of the damp air will be exhausted for energy saving. After drying, open the chamber door and pull out the trolleys for discharging.

Application

5) Chemical and Pharmaceutical industry .

Specification

Model	Capacity(kg/batch)	Power (kw)	Trolley Qty	Tray Qty	Dimensions(mm)
ALW-CT-0	30-50	6	0	12	1380*1100*1600
ALW-CT-I	60-100	9	1	24	1400*1200*2000
ALW-CT-II	120-200	15	2	48	2300*1200*2000
ALW-CT-III	240-380	30	4	96	2300*200*2000
ALW-CT-IIV	360-570	45	6	144	3400*2200*2000
ALW-CT-V	480-760	60	8	192	4600*2200*2100
