Colloid Mill is a fine-fluid materials processing machinery which adopts  stainless steel rotor and stator.It combines a homogenizer, ball mill, three roll machine, shearing machines, Mixers and other variety machinery performance, After processing raw materials,the fineness is 50-200mesh, more than 90% homogeneity.

Colloid mill through high speed relative motion of rotor and stator,make the material get strong shearing force,
friction and high mode vibration.Effectively crush,emulsify,homogeneity material to reach refinedproduct.

Colloid mill machine is used to reduce the particle size of a solid in suspension in a liquid, or to reduce the droplet size of a liquid suspended in another liquid. Colloid mills work on the rotor-stator principle: a rotor turns at high speeds. The resulting high levels of hydraulic shear applied to the process liquid disrupt structures in the fluid. Colloid mills are frequently used to increase the stability of suspensions and emulsions., but can also be used to reduce the particle size of solids in suspensions. Higher shear rates lead to smaller droplets, down to approximately 1 µm which are more resistant to emulsion separation.

model	ALW-100L	ALW-160L	ALW-100Y	ALW-160Y
capacity(kg/hr)	15	35	15	35
voltage(v)	110-240/customized
power(w)	1100	1500	1100	1500
rotate speed(r/min)	2850	1450	2850	1450
product size (mm)	328*310*710	380*380*800	270*270*640	300*300*710
packing sized(mm)	375*345*790	390*390*900	340*340*740	380*350*790
N.W(kg)	26	39	20	39
G.W(kg)	35	47	23	46
