Principle
Material powder particles in the material container (fluidized bed) was boiling in a fluidized state by the heated air is preheated and mixed after purification, the binder solution sprayed into the spray, so some particles to contain a binder pellets, since the hot air drying of materials continue to make pellets in the water evaporates, the adhesive sets, this process is repeated continuously, form an ideal, uniform microporous spherical particles.
Application
◎Pharmaceutical granulation and coating
Granulation: tablet granules, granules for granules, granules for capsules.
Coating: granule, pill protective layer, color preparation, slow release, film, enteric coating.
◎Food granulation and coating
Sugar, coffee, cocoa powder, cream, powdered juice, amino acids, seasonings, puffed food.
◎Pesticide, pigment, dye granulation
◎Drying powder, granule and block materials
Performance characteristics
◎Through powder granulation, improve fluidity and reduce dust flying;
◎Improve the solubility of powder through granulation;
◎Mixing—granulation—drying—completed in one machine (one-step granulation);
◎Using anti-static filter material, the equipment is safe to operate;
◎Binder atomizer adopts multi-fluid spray gun, uniform mist particles, and the qualified rate of finished products is greatly improved;
◎The equipment has no dead corners, and the loading and unloading is light and fast, and the cleaning is clean.
|
Item |
Unit |
5 |
60 |
120 |
200 |
500 |
|
|
Container |
Volume |
L |
22 |
220 |
420 |
670 |
1500 |
|
Diameter |
mm |
400 |
1000 |
1200 |
1400 |
1800 |
|
|
Capacity |
MIn |
Kg |
4 |
30 |
80 |
100 |
250 |
|
Max |
Kg |
6 |
90 |
160 |
300 |
750 |
|
|
Fan |
Capacity |
m³/h |
1200 |
3000 |
4500 |
6000 |
8000 |
|
Pressure |
mmH2O |
375 |
950 |
950 |
950 |
950 |
|
|
Power |
Kw |
4 |
11 |
18.5 |
22 |
45 |
|
|
Steam consumption |
Kg/h |
23 |
141 |
211 |
282 |
451 |
|
|
Electrical heater |
Kw |
18 |
45 |
63 |
96 |
123 |
|
|
Compressed air need |
m3/min |
0.9 |
|||||
|
Heating tempreture |
℃ |
Envionmrntal T.-120 |
|||||
|
Steam pressure |
Mpa |
0.3-0.6 |
|||||
|
Working time |
Min |
45-90 |
|||||
|
Weight |
Kg |
700 |
1100 |
1300 |
1500 |
2000 |
|
|
Overall dimension |
M |
1.2*0.7*2.1 |
1.85*1.4*3 |
2.2*1.65*3.3 |
2.34*1.7*3.8 |
3*2.25*4.4 |
|
